800T Paving Brick Making Machine,hydraulic press block machine,concrete block making machine,
HGMA800 hydraulic block machine equipment is given priority to hydraulic pressure, its electric control system adopts PLC programmable procedure, integrates machine、 electricity、 gas and liquid, by pushing board, feeding material, crush molding.
The hydraulic extrusion products process, molding fast, power saving, products structure highly strength, no pollution, lower noise, energy saving function etc. Equipped with a man-machine interface system, the automatic fault diagnosis, remote monitoring, automatically monitoring of production operating procedures. HSY800 Slag brick making machine technical parameters
hydraulic brick making machine is the production of fly ash autoclaved brick main equipment, fly ash autoclaved brick is fly ash or other slag or lime as raw materials, add lime, gypsum and aggregate, the embryo material preparation, pressing molding, high-efficiency steam Conservation and other technology made.
|
Name / type |
HSY800 |
|
Mixer Model |
JS750 |
|
Host size |
4300×2610×3750(mm) |
|
Molding cycle |
15-20(S) |
|
Weight |
31(T) |
|
Host power |
70(kw) |
|
Rated pressure |
31.5(MPA) |
|
Plant area |
850 (㎡) |
|
PRODUCT |
Specifications |
HSY800 PCS/MOLD |
Molding cycle |
|
SOLID BRICK |
240×115×53 |
36 |
15-20 S |
|
2 HOLES |
220×105×65 |
40 |
25-30 S |
|
4 HOLES |
180×80×80 |
35 |
25-30 S |
|
6 HOLES |
120×180×80 |
28 |
25-30 S |
|
6 HOLES |
220×150×115 |
24 |
25-30 S |
Leave A Message150T Paving Brick Making Machine，HDY1500 hydraulic press block machine,concrete block making machine is specialized in producing concrete road edge stone, concrete hollow block, cement brick, color brick, paving brick, with high pressure, fast forming speed, high density and stable performance
300T Paving Brick Making Machine，Road edge stone brick machine is specialized in producing concrete road edge stone, concrete hollow block, cement brick, color brick, paving brick, with high pressure, fast forming speed, high density and stable performance
600T Brick Making Machine，HDY600 type automatic bin-direction hydraulic molding machine, consists of host machine,electric appliance, control system, hydraulic system, pneumatic system, multifunctional conveyor system, stacking system, feeding unit into a fully automatic production line.
HSY800 block making machine,Double hydraulic press block machine,concrete block making machine,
1000T hydraulic press block machinee brick making machine is the production of fly ash autoclaved brick main equipment, fly ash autoclaved brick is fly ash or other slag or lime as raw materials, add lime, gypsum and aggregate, the embryo material preparation, pressing molding, high-efficiency steam Conservation and other technology made.
The hydraulic system of this machine includes motors, oil pumps, control valve manifolds, oil tanks and other systems and various connecting pipelines. The pipelines of the hydraulic system are all connected by high-pressure flanges to avoid leakage of hydraulic oil. All oil pipes are pickled before welding, and then after welding slag, deburring and secondary pickling to ensure the cleanliness of the hydraulic pipeline.
The powder forming four column hydraulic press is economical and practical. The hydraulic control adopts the integrated system of plug-in setting valve to reduce the discharge point. It has reliable movement, durability and long service life. The first is the constant pressure realization and the secondary development technology of constant pressure program, which has the function of ensuring the differential pressure delay. The stroke of working pressure can be adjusted within the specified range. The centralized control of buttons can realize manual There are three operation forms: semi-automatic and automatic. Specification Unit 400T Nominal force KN 4000 Max. pressure of liquid MPa 25 Stroke of slider mm 500 Max. opening height mm 1400 Working table size mm*mm 1000x800 Speed of slider Descent speed mm/s 340 Working speed mm/s 16-24 Return speed mm/s 220 Motor power KW 22x2
automatic cantilever winding film packaging machine TECHNICAL SPECIFICATIONS Package Size (500-1200)mmx(500-1200)x2200mm(LxWxH) Lifting parts Chain guide rail lifting mechanism, the lifting speed can be adjusted by frequency conversion Cantilever speed 0-20RPM adjustable Conveyor system Conveyor line height: 400mm, speed: 8-15mm, bearing capacity: 2000kg Packaging efficiency ≥25 Torr/h Control System PLC control, adjustable parameters, adjustable film length, automatic sensing of cargo size Membrane system Electric pre-stretching film, the stretching ratio can reach 250%, and the speed can be adjusted by frequency conversion Motor Power Cantilever: 1.1kw; Formwork: 0.37kw; Lifting parts: 0.37kw, top film: 0.37kw Automatic film breaking device Automatic clamping and cutting of the film without any tailing, completely automatic completion by no one power supply 4KVA/AC380V/50Hz, 3PH/N/PE top membrane PE/PVC film, width 1800mm, diameter 100-300mm, height 30-100mm Gas source 0.4-0.6mpa, 350NL/min Stretch film LLDPE stretch film, width: 1800mm, thickness: 20-35mm Equipment size 4500x2200x3500mm(LxWxH)(According to actual situation)
